Industrial gas hot water boiler water treatment equipment
Type selection of softened water equipment for gas hot water boiler
1. First of all, you should provide the system that needs to use softened water: heating / cooling replenishment / process water / steam gas hot water boiler / iron and steel smelting industry / chemical and pharmaceutical industry.
2, system water use time: does the running time / hour water consumption / average / peak / user need continuous water supply? If necessary, select single valve double tank or double control double bed series, otherwise you can choose single valve single tank system.
3. Total hardness of source water: is the source of water municipal tap water? Groundwater? Surface water sources (rivers, lakes) you need to provide the hardness of raw water in the area of use. Yeah, a certain type of water softener. It is said that the water hardness is high, and the periodic water production must be less, which leads to frequent regeneration. It is unfavorable to the service life of the resin. To avoid this, resin volume should be increased, which means the choice of larger models of water softeners.
4, the required soft water unit flow (ton / hour). This is determined by the nature and requirements of the user's equipment to select the standard model of the softener.
5. The setting of periodic water production. After the model of the softener is set, according to the hardness of the raw water, the exchange capacity of the resin can be used to determine the theoretical periodic water production (tons). Working characteristics of softened Water equipment of Gas Hot Water Boiler
1, automatic Control Program The degree is high and the water supply is stable.
2, high efficiency, low energy consumption, low operating cost.
3, excellent corrosion performance: glass fiber reinforced plastic, 304, lined rubber or carbon steel lined resin tank, non-toxic pressure resistance, strong corrosion resistance, fundamentally avoid the possibility of exchanger corrosion. 4, wide range of applications: suitable for industrial and civil gas hot water boilers, heat exchangers, air conditioners and refrigerators frozen water cycle, widely used in hotels, power stations, steel plants, printing and dyeing plants, food and beverage processing plants, cold storage, Shopping malls and other units of water quality softened treatment system.
5, the equipment structure is compact, the area is small, reduces the infrastructure investment. Install, debug, It is simple and easy to use. Stable performance of running parts
